| Mfr. #: | UCC3807N-3 |
|---|---|
| Produttore: | Texas Instruments |
| Descrizione: | Switching Controllers Programmable Maximum Duty Cycle |
| Ciclo vitale: | Nuovo da questo produttore. |
| Scheda dati: | UCC3807N-3 Scheda dati |
Product belongs to the UCC3807-3 series. Tube Alternate Packaging is the packaging method for this product Weight of 0.018455 oz Through Hole Mounting-Style PDIP-8 Operational temperature range: 0°C ~ 70°C (TA) Output-Type: Transistor Driver Product function is Step-Up, Step-Down, Step-Up/Step-Down. Supplier device package: 8-PDIP Number-of-Outputs: 1 Topology: Buck, Boost, Flyback, Forward Converter, SEPIC feedback Supply Voltage: 4.1 V ~ 13.5 V This product features 'Frequency-Switching' at 202kHz for optimal performance. The Control-Features include - function. The Positive. Output-Phases: 1 Maximum duty cycle of 78 % The value of No is included as a product attribute. No enabled Serial Interfaces: - Maximum operating temperature of + 70 C Minimum operating temperature: 0 C Output current: 1000 mA Switching frequency is 1000 kHz This product has a 20 ns of 16 ns. This product has a 20 ns of 16 ns.
