UCC28220PWR

UCC28220PWR Overview

Product belongs to the UCC28220 series. Tape & Reel (TR) Alternate Packaging is the packaging method for this product Weight of 0.002183 oz SMD/SMT Mounting-Style TSSOP-16 Operational temperature range: -40°C ~ 105°C (TA) Output-Type: Transistor Driver Product function is Step-Up/Step-Down. Supplier device package: 16-TSSOP Number-of-Outputs: 2 Topology: Flyback, Forward Converter feedback Supply Voltage: 8.4 V ~ 14.5 V This product features 'Frequency-Switching' at 200kHz ~ 2MHz for optimal performance. The Control-Features include Ramp, Soft Start function. The Positive. Output-Phases: 1 Maximum duty cycle of 90 % The value of No is included as a product attribute. No enabled Serial Interfaces: - Maximum operating temperature of + 105 C Minimum operating temperature: - 40 C Output current: 100000 mA Switching frequency is 2000 kHz This product has a 10 ns of 16 ns. This product has a 10 ns of 16 ns.

UCC28220PWR Image

UCC28220PWR Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Voltage Regulators - DC DC Switching Controllers
• Series UCC28220
• Packaging Tape & Reel (TR) Alternate Packaging
• Unit-Weight 0.002183 oz
• Mounting-Style SMD/SMT
• Package-Case TSSOP-16
• Operating-Temperature -40°C ~ 105°C (TA)
• Output-Type Transistor Driver
• Function Step-Up/Step-Down
• Supplier-Device-Package 16-TSSOP
• Number-of-Outputs 2
• Topology Flyback, Forward Converter
• Voltage-Supply-Vcc-Vdd 8.4 V ~ 14.5 V
• Frequency-Switching 200kHz ~ 2MHz
• Control-Features Ramp, Soft Start
• Output-Configuration Positive
• Output-Phases 1
• Duty-Cycle-Max 90 %
• Synchronous-Rectifier No
• Clock-Sync No
• Serial-Interfaces -
• Maximum-Operating-Temperature + 105 C
• Minimum-Operating-Temperature - 40 C
• Output-Current 100000 mA
• Switching-Frequency 2000 kHz
• Fall-Time 10 ns
• Rise-Time 10 ns
