TS3L301DGG

TS3L301DGG Overview

Product belongs to the 3L series. This product is categorized as LAN Switches Tube Alternate Packaging is the packaging method for this product Weight of 0.007873 oz SMD/SMT Mounting-Style TSSOP-48 Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Product function is Ethernet Switch. Supplier device package: 48-TSSOP - is 8. Voltage supply source: Analog and digital Single Supply Configuration 8 x SPDT Circuit type: 1 x 16:8 8 Ohm maximum on-state resistance Voltage supply range: 3 V ~ 3.6 V This product has a 250μA of 200μA. The - 900 MHz bandwidth Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 3.3 V supply voltage for reliable performance. Maximum supply current: 600 uA Max on-resistance of 8 Ohms Maximum off time: 8.5 ns 8 Switch switch functionality Maximum on-time: 11.5 ns

TS3L301DGG Image

TS3L301DGG Specifications

• Manufacturer Texas Instruments
• Product Category Interface - Analog Switches, Multiplexers, Demultiplexers
• Series 3L
• Product LAN Switches
• Packaging Tube Alternate Packaging
• Unit-Weight 0.007873 oz
• Mounting-Style SMD/SMT
• Package-Case TSSOP-48
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Surface Mount
• Function Ethernet Switch
• Supplier-Device-Package 48-TSSOP
• Number-of-Circuits -
• Voltage-Supply-Source Single Supply
• Configuration 8 x SPDT
• Switch-Circuit -
• Circuit 1 x 16:8
• Multiplexer-Demultiplexer-Circuit -
• On-State-Resistance-Max 8 Ohm
• Channel-to-Channel-Matching-ΔRon -
• Voltage-Supply-Single-Dual 3 V ~ 3.6 V
• Current-Supply 250μA
• Voltage-Supply-Single-V+ -
• Voltage-Supply-Dual-V -
• Switch-Time-Ton-Toff-Max -
• -3db-Bandwidth -
• Charge-Injection -
• Channel-Capacitance-CS-off-CD-off -
• Current-Leakage-IS-off-Max -
• Crosstalk -
• Bandwidth 900 MHz
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 3.3 V
• Supply-Current-Max 600 uA
• On-Resistance-Max 8 Ohms
• Off-Time-Max 8.5 ns
• Number-of-Switches 8 Switch
• On-Time-Max 11.5 ns
