TPS22942DCKR

TPS22942DCKR Overview

Product belongs to the TPS22942 series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.000088 oz SMD/SMT Mounting-Style SOT-23-5 The Non-Inverting for this product is CMOS/TTL. Operational temperature range: -40°C ~ 125°C (TJ) Output-Type: P-Channel Interface: On/Off Supplier device package: SC-70-5 The Ratio-Input:Output for this product is 1899/12/30 1:01:00. Number-of-Outputs: 1 Supply Voltage: Not Required The High Side. The 400 mOhm. Voltage-Load range is 1.62 V ~ 5.5 V. Our product delivers a 100mA of 50mA for efficient power management. The Switch-Type is General Purpose. Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 1.62 V to 5.5 V supply voltage for reliable performance. Maximum supply voltage of 5.5 V Minimum supply voltage is 1.62 V Max on-resistance of 400 mOhms Maximum off time: 30 us This product's 100 mA feature is adjustable. Maximum on-time: 60 us

TPS22942DCKR Image

TPS22942DCKR Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Power Distribution Switches, Load Drivers
• Series TPS22942
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.000088 oz
• Mounting-Style SMD/SMT
• Package-Case SOT-23-5
• Input-Type Non-Inverting
• Operating-Temperature -40°C ~ 125°C (TJ)
• Output-Type P-Channel
• Features Auto Restart
• Interface On/Off
• Supplier-Device-Package SC-70-5
• Ratio-Input:Output 1899/12/30 1:01:00
• Number-of-Outputs 1
• Voltage-Supply-Vcc-Vdd Not Required
• Fault-Protection Current Limiting (Fixed), Over Temperature, UVLO
• Output-Configuration High Side
• Rds-On-Typ 400 mOhm
• Voltage-Load 1.62 V ~ 5.5 V
• Current-Output-Max 100mA
• Switch-Type General Purpose
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 1.62 V to 5.5 V
• Supply-Voltage-Max 5.5 V
• Supply-Voltage-Min 1.62 V
• On-Resistance-Max 400 mOhms
• Off-Time-Max 30 us
• Current-Limit 100 mA
• On-Time-Max 60 us
