TLC5941RHBR

TLC5941RHBR Overview

Product belongs to the TLC5941 series. Type: Linear Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.002547 oz SMD/SMT Mounting-Style VQFN-32 This product's - range is 0Hz to 2.2GHz. Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Versatile Backlight, Signage applications for maximum usability Supplier device package: 32-VQFN (5x5) Number-of-Outputs: 16 Current-Output-Channel is 80mA This product has Yes. Topology: Shift Register feedback The maximum voltage supply is 5.5V. The minimum 3V required for voltage supply. Output voltage: 17V Dimming control is done through - communication. Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 3 V to 5.5 V supply voltage for reliable performance. Maximum supply current: 60 mA This product is also known as HPA00219RHBR and can be referred to by either part number. High-Level-Output-Current of - 1 mA 1 mA low-level output current

TLC5941RHBR Image

TLC5941RHBR Specifications

• Manufacturer TI
• Product Category PMIC - LED Drivers
• Series TLC5941
• Type Linear
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.002547 oz
• Mounting-Style SMD/SMT
• Package-Case VQFN-32
• Frequency -
• Operating-Temperature -40°C ~ 85°C (TA)
• Mounting-Type Surface Mount
• Applications Backlight, Signage
• Supplier-Device-Package 32-VQFN (5x5)
• Number-of-Outputs 16
• Current-Output-Channel 80mA
• Internal-Switch-s Yes
• Topology Shift Register
• Voltage-Supply-Max 5.5V
• Voltage-Supply-Min 3V
• Voltage-Output 17V
• Dimming -
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 3 V to 5.5 V
• Supply-Current-Max 60 mA
• Part-#-Aliases HPA00219RHBR
• High-Level-Output-Current - 1 mA
• Low-Level-Output-Current 1 mA
