TLC5921DAPR

TLC5921DAPR Overview

Product belongs to the TLC5921 series. Type: Linear Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.006388 oz SMD/SMT Mounting-Style HTSSOP-32 This product's 20MHz range is 0Hz to 2.2GHz. Operational temperature range: -20°C ~ 85°C (TA) Surface Mount mounting type Output-Type: Constant Current Versatile - applications for maximum usability Supplier device package: 32-HTSSOP Number-of-Outputs: 16 Current-Output-Channel is 80mA This product has Yes. Topology: Shift Register feedback The maximum voltage supply is 5.5V. The minimum 4.5V required for voltage supply. Output voltage: 17V Dimming control is done through - communication. Power-off control: 3.9 W Maximum operating temperature of + 85 C Minimum operating temperature: - 20 C The operating frequency is 20 MHz. Input Voltage Range: 4.5 V to 5.5 V Output current: 80 mA Maximum supply current: 50 mA This product is also known as HPA00208DAPR HPA00209DAPR and can be referred to by either part number. High-Level-Output-Current of - 1 mA 1 mA low-level output current

TLC5921DAPR Image

TLC5921DAPR Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - LED Drivers
• Series TLC5921
• Type Linear
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.006388 oz
• Mounting-Style SMD/SMT
• Package-Case HTSSOP-32
• Frequency 20MHz
• Operating-Temperature -20°C ~ 85°C (TA)
• Mounting-Type Surface Mount
• Output-Type Constant Current
• Applications -
• Supplier-Device-Package 32-HTSSOP
• Number-of-Outputs 16
• Current-Output-Channel 80mA
• Internal-Switch-s Yes
• Topology Shift Register
• Voltage-Supply-Max 5.5V
• Voltage-Supply-Min 4.5V
• Voltage-Output 17V
• Dimming -
• Pd-Power-Dissipation 3.9 W
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 20 C
• Operating-Frequency 20 MHz
• Input-Voltage 4.5 V to 5.5 V
• Output-Current 80 mA
• Supply-Current-Max 50 mA
• Part-#-Aliases HPA00208DAPR HPA00209DAPR
• High-Level-Output-Current - 1 mA
• Low-Level-Output-Current 1 mA
