TC2320TG-G

TC2320TG-G Overview

Product belongs to the - series. Tape & Reel (TR) is the packaging method for this product Weight of 0.002998 oz SMD/SMT Mounting-Style 8-SOIC (0.154", 3.90mm Width) Si is the technology used. Operational temperature range: -55°C ~ 150°C (TJ) Surface Mount mounting type Number of channels: 2 Channel Supplier device package: 8-SOIC Configuration Dual Dual Drain This product uses an N and P-Channel FET-Type transistor. Transistor type: 1 N-Channel 1 P-Channel 200V This product has an 110pF @ 25V value of 300pF @ 25V. This product's Standard. - continuous drain-ID current at 25°C; This product has an 7 Ohm @ 1A, 10V of 12 Ohm @ 150mA, 0V. Maximum operating temperature of + 150 C Minimum operating temperature: - 55 C This product has a 15 ns of 16 ns. This product has a 15 ns of 16 ns. This product's 20 V. The ID of continuous drain current is 2 A. This product has a Vds-Drain-Source-Breakdown-Voltageof 200 V. The 7 Ohms 12 Ohms for this product is 12 Ohms. The transistor polarity is N-Channel P-Channel. 'Typical-Turn-Off-Delay-Time' of 25 ns 20 ns This product has a 20 ns 10 ns. This product operates in Enhancement channel mode for optimal performance.

TC2320TG-G Image

TC2320TG-G Specifications

• Manufacturer Microchip Technology
• Product Category FETs - Arrays
• Series -
• Packaging Tape & Reel (TR)
• Unit-Weight 0.002998 oz
• Mounting-Style SMD/SMT
• Package-Case 8-SOIC (0.154", 3.90mm Width)
• Technology Si
• Operating-Temperature -55°C ~ 150°C (TJ)
• Mounting-Type Surface Mount
• Number-of-Channels 2 Channel
• Supplier-Device-Package 8-SOIC
• Configuration Dual Dual Drain
• FET-Type N and P-Channel
• Power-Max -
• Transistor-Type 1 N-Channel 1 P-Channel
• Drain-to-Source-Voltage-Vdss 200V
• Input-Capacitance-Ciss-Vds 110pF @ 25V
• FET-Feature Standard
• Current-Continuous-Drain-Id-25°C -
• Rds-On-Max-Id-Vgs 7 Ohm @ 1A, 10V
• Vgs-th-Max-Id 2V @ 1mA
• Gate-Charge-Qg-Vgs -
• Maximum-Operating-Temperature + 150 C
• Minimum-Operating-Temperature - 55 C
• Fall-Time 15 ns
• Rise-Time 15 ns
• Vgs-Gate-Source-Voltage 20 V
• Id-Continuous-Drain-Current 2 A
• Vds-Drain-Source-Breakdown-Voltage 200 V
• Rds-On-Drain-Source-Resistance 7 Ohms 12 Ohms
• Transistor-Polarity N-Channel P-Channel
• Typical-Turn-Off-Delay-Time 25 ns 20 ns
• Typical-Turn-On-Delay-Time 20 ns 10 ns
• Channel-Mode Enhancement
