STN3NF06

STN3NF06 Overview

Product belongs to the STripFET II series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.008826 oz SMD/SMT Mounting-Style TO-261-4, TO-261AA Si is the technology used. Operational temperature range: -55°C ~ 150°C (TJ) Surface Mount mounting type Number of channels: 1 Channel Supplier device package: SOT-223 Configuration Single This product uses an MOSFET N-Channel, Metal Oxide FET-Type transistor. Transistor type: 1 N-Channel 60V This product has an 315pF @ 25V value of 300pF @ 25V. This product's Standard. 4A (Tc) continuous drain-ID current at 25°C; This product has an 100 mOhm @ 1.5A, 10V of 12 Ohm @ 150mA, 0V. Power-off control: 3.3 W Maximum operating temperature of + 150 C Minimum operating temperature: - 55 C This product has a 6 ns of 16 ns. This product has a 18 ns of 16 ns. This product's 20 V. The ID of continuous drain current is 4 A. This product has a Vds-Drain-Source-Breakdown-Voltageof 60 V. The 70 mOhms for this product is 12 Ohms. The transistor polarity is N-Channel. 'Typical-Turn-Off-Delay-Time' of 17 ns This product has a 7 ns. This product features a 3 S of 500 S for high performance. This product operates in Enhancement channel mode for optimal performance.

STN3NF06 Image

STN3NF06 Specifications

• Manufacturer STMicroelectronics
• Product Category FETs - Single
• Series STripFET II
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.008826 oz
• Mounting-Style SMD/SMT
• Package-Case TO-261-4, TO-261AA
• Technology Si
• Operating-Temperature -55°C ~ 150°C (TJ)
• Mounting-Type Surface Mount
• Number-of-Channels 1 Channel
• Supplier-Device-Package SOT-223
• Configuration Single
• FET-Type MOSFET N-Channel, Metal Oxide
• Power-Max 3.3W
• Transistor-Type 1 N-Channel
• Drain-to-Source-Voltage-Vdss 60V
• Input-Capacitance-Ciss-Vds 315pF @ 25V
• FET-Feature Standard
• Current-Continuous-Drain-Id-25°C 4A (Tc)
• Rds-On-Max-Id-Vgs 100 mOhm @ 1.5A, 10V
• Vgs-th-Max-Id 4V @ 250μA
• Gate-Charge-Qg-Vgs 13nC @ 10V
• Pd-Power-Dissipation 3.3 W
• Maximum-Operating-Temperature + 150 C
• Minimum-Operating-Temperature - 55 C
• Fall-Time 6 ns
• Rise-Time 18 ns
• Vgs-Gate-Source-Voltage 20 V
• Id-Continuous-Drain-Current 4 A
• Vds-Drain-Source-Breakdown-Voltage 60 V
• Rds-On-Drain-Source-Resistance 70 mOhms
• Transistor-Polarity N-Channel
• Typical-Turn-Off-Delay-Time 17 ns
• Typical-Turn-On-Delay-Time 7 ns
• Forward-Transconductance-Min 3 S
• Channel-Mode Enhancement
