STL8N10LF3

STL8N10LF3 Overview

Product belongs to the STripFET III series. Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style 8-PowerSMD, Flat Leads Si is the technology used. Operational temperature range: -55°C ~ 175°C (TJ) Surface Mount mounting type Number of channels: 1 Channel Supplier device package: PowerFlat (5x6) Configuration Single This product uses an MOSFET N-Channel, Metal Oxide FET-Type transistor. Transistor type: 1 N-Channel 100V This product has an 970pF @ 25V value of 300pF @ 25V. This product's Logic Level Gate. 20A (Tc) continuous drain-ID current at 25°C; This product has an 35 mOhm @ 4A, 10V of 12 Ohm @ 150mA, 0V. Power-off control: 70 W Maximum operating temperature of + 175 C Minimum operating temperature: - 55 C This product has a 5.2 ns of 16 ns. This product has a 9.6 ns of 16 ns. This product's 20 V. The ID of continuous drain current is 7.8 A. This product has a Vds-Drain-Source-Breakdown-Voltageof 100 V. This product has a 1 V to 3 V Vgs-th gate-source threshold voltage for efficient power management. The 35 mOhms for this product is 12 Ohms. The transistor polarity is N-Channel. 'Typical-Turn-Off-Delay-Time' of 50.6 ns This product has a 8.7 ns. Qg-Gate-Charge is 20.5 nC.

STL8N10LF3 Image

STL8N10LF3 Specifications

• Manufacturer STMicroelectronics
• Product Category FETs - Single
• Series STripFET III
• Packaging Digi-ReelR Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case 8-PowerSMD, Flat Leads
• Technology Si
• Operating-Temperature -55°C ~ 175°C (TJ)
• Mounting-Type Surface Mount
• Number-of-Channels 1 Channel
• Supplier-Device-Package PowerFlat (5x6)
• Configuration Single
• FET-Type MOSFET N-Channel, Metal Oxide
• Power-Max 70W
• Transistor-Type 1 N-Channel
• Drain-to-Source-Voltage-Vdss 100V
• Input-Capacitance-Ciss-Vds 970pF @ 25V
• FET-Feature Logic Level Gate
• Current-Continuous-Drain-Id-25°C 20A (Tc)
• Rds-On-Max-Id-Vgs 35 mOhm @ 4A, 10V
• Vgs-th-Max-Id 3V @ 250μA
• Gate-Charge-Qg-Vgs 20.5nC @ 10V
• Pd-Power-Dissipation 70 W
• Maximum-Operating-Temperature + 175 C
• Minimum-Operating-Temperature - 55 C
• Fall-Time 5.2 ns
• Rise-Time 9.6 ns
• Vgs-Gate-Source-Voltage 20 V
• Id-Continuous-Drain-Current 7.8 A
• Vds-Drain-Source-Breakdown-Voltage 100 V
• Vgs-th-Gate-Source-Threshold-Voltage 1 V to 3 V
• Rds-On-Drain-Source-Resistance 35 mOhms
• Transistor-Polarity N-Channel
• Typical-Turn-Off-Delay-Time 50.6 ns
• Typical-Turn-On-Delay-Time 8.7 ns
• Qg-Gate-Charge 20.5 nC
