| Mfr. #: | STGW39NC60VD |
|---|---|
| Produttore: | STMicroelectronics |
| Descrizione: | IGBT 600V 80A 250W TO247 |
| Ciclo vitale: | Nuovo da questo produttore. |
| Scheda dati: | STGW39NC60VD Scheda dati |
Product belongs to the PowerMESH series. Tube is the packaging method for this product Weight of 1.340411 oz Through Hole Mounting-Style TO-247-3 The Standard for this product is CMOS/TTL. Through Hole mounting type Supplier device package: TO-247-3 Configuration Single Maximum current collector Ic is 80A . Maximum collector-emitter breakdown voltage of 600V The Current-Collector-Pulsed-Icm is rated at 220A. The Vce-on-Max-Vge-Ic is rated at 2.4V @ 15V, 30A. 33ns/178ns Td-on-off at 25°C; Operating temperature: 390V, 30A, 10 Ohm, 15V Power-off control: 250 W Maximum operating temperature of + 150 C Minimum operating temperature: - 55 C Rated VCEO up to 600 V Saturation voltage between collector and emitter is 1.8 V/1.7 V Maximum-Gate-Emitter-Voltage: +/- 20 V Maximal 80 A Collector Current of Continuity;
