ST1L05APU33R

ST1L05APU33R Overview

Product belongs to the ST1L05 series. Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style DFN-EP-6 Operational temperature range: 0°C ~ 125°C Surface Mount mounting type Output-Type: Fixed Supplier device package: 6-DFN (3x3) 4.5 V ~ 5.5 V voltage input Number-of-Outputs: 1 Output Output voltage: 3.3V Positive Fixed regulator topology The product has 1 of 1. Maximum operating temperature of + 125 C Minimum operating temperature: 0 C Output voltage: 3.3 V Maximum Input Voltage: 5.5 V Output current: 1.3 A The product's 3 V is 5.1 V. Load regulation is 30 mV. The voltage regulation accuracy of this product is 2 %. Input bias current of 350 uA This product has a 500 uA of 7 mA, making it ideal for low-power applications. The 0.2 V at 800 mA. The maximum 400 mV at 800 mA is 360 mV. This product's 15 mV is 0.01 %/V.

ST1L05APU33R Image

ST1L05APU33R Specifications

• Manufacturer STMicroelectronics
• Product Category PMIC - Voltage Regulators - Linear
• Series ST1L05
• Packaging Digi-ReelR Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case DFN-EP-6
• Operating-Temperature 0°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type Fixed
• Supplier-Device-Package 6-DFN (3x3)
• Voltage-Input 4.5 V ~ 5.5 V
• Number-of-Outputs 1 Output
• Current-Output 1.3A
• Voltage-Output 3.3V
• Regulator-Topology Positive Fixed
• Voltage-Dropout-Typical 0.3V @ 1.3A
• Number-of-Regulators 1
• Current-Limit-Min 1.3A
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature 0 C
• Output-Voltage 3.3 V
• Input-Voltage-MAX 5.5 V
• Output-Current 1.3 A
• Input-Voltage-MIN 3 V
• Load-Regulation 30 mV
• Voltage-Regulation-Accuracy 2 %
• Ib-Input-Bias-Current 350 uA
• Quiescent-Current 500 uA
• Dropout-Voltage 0.2 V at 800 mA
• Dropout-Voltage-Max 400 mV at 800 mA
• Line-Regulation 15 mV
