SN74LVCU04APWR

SN74LVCU04APWR Overview

Product belongs to the 74LVCU series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.002018 oz SMD/SMT Mounting-Style Wide - 40 C to + 85 C operating temperature range for diverse applications TSSOP-14 The CMOS TTL for this product is CMOS/TTL. Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Output-Type: CMOS Voltage Supply Range: 1.65 V ~ 3.6 V Supplier device package: 14-TSSOP 6 is 8. 10μA maximum quiescent current. Inverter logic type 0.4 V ~ 0.65 V is a Logic-Level-Low; 1.32 V ~ 2.88 V is the Logic-Level-High Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Maximum supply voltage of 3.6 V Minimum supply voltage is 2 V LVC logic type 3.8 ns is 23 microseconds. High-Level-Output-Current of - 24 mA 24 mA low-level output current

SN74LVCU04APWR Image

SN74LVCU04APWR Specifications

• Manufacturer Texas Instruments
• Product Category Logic - Gates and Inverters
• Series 74LVCU
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.002018 oz
• Mounting-Style SMD/SMT
• Operating-Temperature-Range - 40 C to + 85 C
• Package-Case TSSOP-14
• Input-Type CMOS TTL
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Surface Mount
• Output-Type CMOS
• Features -
• Voltage-Supply 1.65 V ~ 3.6 V
• Supplier-Device-Package 14-TSSOP
• Number-of-Circuits 6
• Number-of-Inputs 6
• Current-Quiescent-Max 10μA
• Current-Output-High-Low 24mA, 24mA
• Max-Propagation-Delay-V-Max-CL 3.8ns @ 3.3V, 50pF
• Logic-Type Inverter
• Logic-Level-Low 0.4 V ~ 0.65 V
• Logic-Level-High 1.32 V ~ 2.88 V
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Supply-Voltage-Max 3.6 V
• Supply-Voltage-Min 2 V
• Logic-Family LVC
• Propagation-Delay-Time 3.8 ns
• High-Level-Output-Current - 24 mA
• Low-Level-Output-Current 24 mA
