SN74LV14ADGVR

SN74LV14ADGVR Overview

Product belongs to the 74LV series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.001474 oz SMD/SMT Mounting-Style Wide - 40 C to + 85 C operating temperature range for diverse applications TVSOP-14 The LVTTL for this product is CMOS/TTL. Operational temperature range: -40°C ~ 125°C Surface Mount mounting type Output-Type: CMOS Voltage Supply Range: 2 V ~ 5.5 V Supplier device package: 14-TVSOP 6 is 8. 20μA maximum quiescent current. Inverter logic type 0.75 V ~ 1.5 V is a Logic-Level-Low; 1.75 V ~ 3.5 V is the Logic-Level-High Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Maximum supply voltage of 5.5 V Minimum supply voltage is 2 V LV-A logic type 12 ns is 23 microseconds. High-Level-Output-Current of - 12 mA 12 mA low-level output current

SN74LV14ADGVR Image

SN74LV14ADGVR Specifications

• Manufacturer Texas Instruments
• Product Category Logic - Gates and Inverters
• Series 74LV
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.001474 oz
• Mounting-Style SMD/SMT
• Operating-Temperature-Range - 40 C to + 85 C
• Package-Case TVSOP-14
• Input-Type LVTTL
• Operating-Temperature -40°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type CMOS
• Features Schmitt Trigger
• Voltage-Supply 2 V ~ 5.5 V
• Supplier-Device-Package 14-TVSOP
• Number-of-Circuits 6
• Number-of-Inputs 6
• Current-Quiescent-Max 20μA
• Current-Output-High-Low 12mA, 12mA
• Max-Propagation-Delay-V-Max-CL 10.6ns @ 5V, 50pF
• Logic-Type Inverter
• Logic-Level-Low 0.75 V ~ 1.5 V
• Logic-Level-High 1.75 V ~ 3.5 V
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Supply-Voltage-Max 5.5 V
• Supply-Voltage-Min 2 V
• Logic-Family LV-A
• Propagation-Delay-Time 12 ns
• High-Level-Output-Current - 12 mA
• Low-Level-Output-Current 12 mA
