| Mfr. #: | SN74AS244ADW |
|---|---|
| Produttore: | Texas Instruments |
| Descrizione: | Buffers & Line Drivers Octal Buffer/Driver With 3-State Outputs |
| Ciclo vitale: | Nuovo da questo produttore. |
| Scheda dati: | SN74AS244ADW Scheda dati |
Product belongs to the 74AS series. Tube Alternate Packaging is the packaging method for this product Weight of 0.017662 oz SMD/SMT Mounting-Style SOIC-20 Operational temperature range: 0°C ~ 70°C Surface Mount mounting type Output-Type: 3-State Number of channels: 8 Voltage Supply Range: 4.5 V ~ 5.5 V Supplier device package: 20-SOIC 2 element Buffer/Line Driver, Non-Inverting logic type 4 bits per element Maximum operating temperature of + 70 C Minimum operating temperature: 0 C Polarity: Non-Inverting 24 uA is 92 nA. Maximum supply voltage of 5.5 V Minimum supply voltage is 4.5 V AS logic type 6.2 ns at 4.5 V to 5.5 V is 23 microseconds. High-Level-Output-Current of - 15 mA 64 mA low-level output current Number-of-Input-Lines: 8 Input Number-of-Output-Lines: 3 Output
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
SN74AS244ADW Specifications
