SI8261BCD-C-IM Overview

Product belongs to the Automotive, AEC-Q100 series. This product is categorized as Driver ICs - Various Type: IGBT and MOSFET Driver Tray Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style LGA-8 Capacitive Coupling is the technology used. Operational temperature range: -40°C ~ 125°C Surface Mount mounting type Number of channels: 1 Voltage Supply Range: 13.5 V ~ 30 V Supplier device package: 8-LGA (10x12.5) Configuration Single Number-of-Outputs: 2 The product's 4A is 4A. This product is designed with 5000Vrms voltage isolation for maximum safety and reliability. This product has received CQC, CSA, UR, VDE approvals for safety and reliability. Power-off control: No Minimum 35kV/μs of 10kV/μs Maximum Propagation Delay tpLH/tpHL: 60ns, 50ns The minimum pulse width distortion is 28ns. Power-off control: 300 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Output voltage: 0.25 V 2 mA is 92 nA. Output current: 10 mA This product has a 8.5 ns of 16 ns. This product has a 5.5 ns of 16 ns. Maximum supply voltage of 30 V Minimum supply voltage is 5 V Number-of-Drivers: 1 Driver

SI8261BCD-C-IM Image

SI8261BCD-C-IM Specifications

• Manufacturer Silicon Labs
• Product Category Isolators - Gate Drivers
• Series Automotive, AEC-Q100
• Product Driver ICs - Various
• Type IGBT and MOSFET Driver
• Packaging Tray Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case LGA-8
• Technology Capacitive Coupling
• Operating-Temperature -40°C ~ 125°C
• Mounting-Type Surface Mount
• Number-of-Channels 1
• Voltage-Supply 13.5 V ~ 30 V
• Supplier-Device-Package 8-LGA (10x12.5)
• Configuration Single
• Number-of-Outputs 2
• Current-Output-High-Low 500mA, 1.2A
• Current-Peak-Output 4A
• Current-DC-Forward-If-Max 30mA
• Voltage-Isolation 5000Vrms
• Approvals CQC, CSA, UR, VDE
• Shutdown No
• Voltage-Forward-Vf-Typ 2.8V (Max)
• Rise-Fall-Time-Typ 5.5ns, 8.5ns
• Common-Mode-Transient-Immunity-Min 35kV/μs
• Propagation-Delay-tpLH-tpHL-Max 60ns, 50ns
• Pulse-Width-Distortion-Max 28ns
• Pd-Power-Dissipation 300 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Output-Voltage 0.25 V
• Operating-Supply-Current 2 mA
• Output-Current 10 mA
• Fall-Time 8.5 ns
• Rise-Time 5.5 ns
• Supply-Voltage-Max 30 V
• Supply-Voltage-Min 5 V
• Number-of-Drivers 1 Driver
