PIC32MX564F128L-I/PT

PIC32MX564F128L-I/PT Overview

Product belongs to the PICR 32MX series. This product is categorized as MCU Tray Alternate Packaging is the packaging method for this product Weight of 0.023175 oz SMD/SMT Mounting-Style TQFP-100 Operational temperature range: -40°C ~ 85°C (TA) Supplier device package: 100-TQFP (12x12) This product has 85 I/O ports for versatile connectivity. Operating frequency: 80MHz Program memory type: FLASH CAN, I2C, SPI, UART/USART, USB OTG interface Supply Voltage: 2.3 V ~ 3.6 V 32-Bit architecture Internal oscillator type Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 2.3 V to 3.6 V supply voltage for reliable performance. I2C SPI USART interface type Processor Core: MIPS32 M4K This product is powered by the PIC32MX5 Processor-Series, providing high performance and efficiency. The 32 bit. Maximum supply voltage of 3.6 V Minimum supply voltage is 2.3 V Maximum clock frequency of 80 MHz Number of ADC Channels: 16 Channel This product has 85 I/O connections. This product has a 32 kB data RAM size, providing ample storage for complex applications. This product features 5 x 16 bit number of timers and counters. This product includes Watchdog Timer This product features a high-precision 10 bit, ensuring accurate data conversion. This product utilizes SRAM, providing fast and efficient data storage.

PIC32MX564F128L-I/PT Image

PIC32MX564F128L-I/PT Specifications

• Manufacturer Microchip Technology
• Product Category IC Chips
• Series PICR 32MX
• Product MCU
• Packaging Tray Alternate Packaging
• Unit-Weight 0.023175 oz
• Mounting-Style SMD/SMT
• Package-Case TQFP-100
• Operating-Temperature -40°C ~ 85°C (TA)
• Supplier-Device-Package 100-TQFP (12x12)
• Number-of-I-O 85
• Speed 80MHz
• EEPROM-Size -
• Core-Processor MIPS32R M4K
• RAM-Size 32K x 8
• Program-Memory-Type FLASH
• Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
• Connectivity CAN, I2C, SPI, UART/USART, USB OTG
• Voltage-Supply-Vcc-Vdd 2.3 V ~ 3.6 V
• Core-Size 32-Bit
• Program-Memory-Size 128KB (128K x 8)
• Data-Converters A/D 16x10b
• Oscillator-Type Internal
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 2.3 V to 3.6 V
• Interface-Type I2C SPI USART
• Core MIPS32 M4K
• Processor-Series PIC32MX5
• Data-Bus-Width 32 bit
• Supply-Voltage-Max 3.6 V
• Supply-Voltage-Min 2.3 V
• Maximum-Clock-Frequency 80 MHz
• Number-of-ADC-Channels 16 Channel
• Number-of-I-Os 85 I/O
• Data-RAM-Size 32 kB
• Number-of-Timers-Counters 5 x 16 bit
• Watchdog-Timers Watchdog Timer
• ADC-Resolution 10 bit
• Data-RAM-Type SRAM
