| Mfr. #: | LM3630ATME |
|---|---|
| Produttore: | Texas Instruments |
| Descrizione: | LED Lighting Drivers Hi Eff Dual-String White LED Dv |
| Ciclo vitale: | Nuovo da questo produttore. |
| Scheda dati: | LM3630ATME Scheda dati |
Product belongs to the LM3630A series. Type: DC DC Regulator Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style DSBGA-12 This product's - range is 0Hz to 2.2GHz. Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Output-Type: Current Mode Versatile Backlight applications for maximum usability Supplier device package: 12-DSBGA Number-of-Outputs: 2 Current-Output-Channel is 28.5mA This product has Yes. Topology: Step-Up (Boost) feedback The maximum voltage supply is 5.5V. The minimum 2.3V required for voltage supply. Output voltage: - Dimming control is done through PWM communication. Power-off control: Internally Limited Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C The operating frequency is 500 kHz 1 MHz. Input Voltage Range: 2.3 V to 5.5 V Output current: 20 mA Maximum supply current: 350 uA
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
LM3630ATME Specifications
