LM2990S-12

LM2990S-12 Overview

Product belongs to the LM2990 series. Tube Alternate Packaging is the packaging method for this product Weight of 0.068654 oz SMD/SMT Mounting-Style TO-263-3 Operational temperature range: -40°C ~ 125°C Surface Mount mounting type Output-Type: Fixed Supplier device package: DDPAK/TO-263-3 Down to -26V voltage input Number-of-Outputs: 1 Output Output voltage: -12V Negative Fixed regulator topology The product has 1 of 1. Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Output voltage: - 12 V Maximum Input Voltage: 300 mV Output current: 1.8 A The product's - 26 V is 5.1 V. Load regulation is 50 mV. The voltage regulation accuracy of this product is +/- 5 %. Input bias current of 1 mA This product has a 5 mA of 7 mA, making it ideal for low-power applications. The 0.1 V at 100 mA 0.6 V at 1 A. The maximum 0.3 V at 100 mA 1 V at 1 A is 360 mV. This product's 60 mV is 0.01 %/V.

LM2990S-12 Image

LM2990S-12 Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Voltage Regulators - Linear
• Series LM2990
• Packaging Tube Alternate Packaging
• Unit-Weight 0.068654 oz
• Mounting-Style SMD/SMT
• Package-Case TO-263-3
• Operating-Temperature -40°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type Fixed
• Supplier-Device-Package DDPAK/TO-263-3
• Voltage-Input Down to -26V
• Number-of-Outputs 1 Output
• Current-Output 1.8A
• Voltage-Output -12V
• Regulator-Topology Negative Fixed
• Voltage-Dropout-Typical 0.6V @ 1A
• Number-of-Regulators 1
• Current-Limit-Min -
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Output-Voltage - 12 V
• Input-Voltage-MAX 300 mV
• Output-Current 1.8 A
• Input-Voltage-MIN - 26 V
• Load-Regulation 50 mV
• Voltage-Regulation-Accuracy +/- 5 %
• Ib-Input-Bias-Current 1 mA
• Quiescent-Current 5 mA
• Dropout-Voltage 0.1 V at 100 mA 0.6 V at 1 A
• Dropout-Voltage-Max 0.3 V at 100 mA 1 V at 1 A
• Line-Regulation 60 mV
