LM1084IS-ADJ

LM1084IS-ADJ Overview

Product belongs to the LM1084 series. Tube is the packaging method for this product Weight of 0.068654 oz SMD/SMT Mounting-Style TO-263-3 Operational temperature range: -40°C ~ 125°C Surface Mount mounting type Output-Type: Adjustable Supplier device package: DDPAK/TO-263-3 2.6 V ~ 29 V voltage input Number-of-Outputs: 1 Output Output voltage: 1.2 V ~ 15 V Positive Adjustable regulator topology The product has 1 of 1. Power-off control: 30000 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Output voltage: 1.25 V Maximum Input Voltage: 29 V Output current: 5 A The product's 2.6 V is 5.1 V. Load regulation is 0.3 %. Reference voltage is 1.262 V . The 1.3 V at 5 A. The maximum 1.5 V at 5 A is 360 mV. This product's 0.2 % is 0.01 %/V.

LM1084IS-ADJ Image

LM1084IS-ADJ Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Voltage Regulators - Linear
• Series LM1084
• Packaging Tube
• Unit-Weight 0.068654 oz
• Mounting-Style SMD/SMT
• Package-Case TO-263-3
• Operating-Temperature -40°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type Adjustable
• Supplier-Device-Package DDPAK/TO-263-3
• Voltage-Input 2.6 V ~ 29 V
• Number-of-Outputs 1 Output
• Current-Output 5A
• Voltage-Output 1.2 V ~ 15 V
• Regulator-Topology Positive Adjustable
• Voltage-Dropout-Typical 1.3V @ 5A
• Number-of-Regulators 1
• Current-Limit-Min 5.5A
• Pd-Power-Dissipation 30000 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Output-Voltage 1.25 V
• Input-Voltage-MAX 29 V
• Output-Current 5 A
• Input-Voltage-MIN 2.6 V
• Load-Regulation 0.3 %
• Reference-Voltage 1.262 V
• Dropout-Voltage 1.3 V at 5 A
• Dropout-Voltage-Max 1.5 V at 5 A
• Line-Regulation 0.2 %
