| Mfr. #: | L5991D013TR |
|---|---|
| Produttore: | STMicroelectronics |
| Descrizione: | IC REG CTRLR PWM CM 16-SOIC |
| Ciclo vitale: | Nuovo da questo produttore. |
| Scheda dati: | L5991D013TR Scheda dati |
Product belongs to the L5991 series. Cut Tape (CT) Alternate Packaging is the packaging method for this product Weight of 0.007079 oz SMD/SMT Mounting-Style SO-16 Operational temperature range: -40°C ~ 150°C (TJ) * mounting type Supplier device package: 16-SO Number-of-Outputs: 1 Output Output-Isolation: Isolated This product has No. Topology: Boost, Flyback feedback Supply Voltage: 10 V ~ 20 V This product features 'Frequency-Switching' at Up to 1MHz for optimal performance. The Control-Features include Frequency Control, Soft Start, Sync function. Maximum operating temperature of + 150 C Minimum operating temperature: - 40 C This product operates at a 12 V to 20 V supply voltage for reliable performance. Output voltage: 5.075 V Output current: 1500 mA Switching frequency is 1000 kHz This product has a 35 ns of 16 ns. This product has a 70 ns of 16 ns. Maximum duty cycle of 93 %
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
L5991D013TR Specifications
