HMC414MS8GE

HMC414MS8GE Overview

Product belongs to the HMC414 series. Type: RF Amplifier Cut Strip Alternate Packaging is the packaging method for this product Weight of 0.004938 oz SMD/SMT Mounting-Style MSOP-8 This product's 2.2GHz ~ 2.8GHz range is 0Hz to 2.2GHz. GaAs InGaP is the technology used. Frequency Bandwidth: 2.2 GHz to 2.8 GHz Number of channels: 1 Channel Voltage Supply Range: 2.75 V ~ 5 V Supplier device package: 8-SMD This product has a 300mA of 200μA. The device offers a 20dB of 26dB. The amplifier is of Power type. Test-Frequency is -. P1dB is 27dBm RF-Type: Bluetooth Power-off control: 1.755 W Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 5 V supply voltage for reliable performance. 300 mA is 92 nA. The operating frequency is 2.8 GHz. NF-Noise-Figure is 7 dB 39 dBm OIP3 third-order intercept The 8 dB is 12 dB.

HMC414MS8GE Image

HMC414MS8GE Specifications

• Manufacturer Analog Devices Inc.
• Product Category RF Amplifiers
• Series HMC414
• Type RF Amplifier
• Packaging Cut Strip Alternate Packaging
• Unit-Weight 0.004938 oz
• Mounting-Style SMD/SMT
• Package-Case MSOP-8
• Frequency 2.2GHz ~ 2.8GHz
• Technology GaAs InGaP
• Frequency-Range 2.2 GHz to 2.8 GHz
• Number-of-Channels 1 Channel
• Voltage-Supply 2.75 V ~ 5 V
• Supplier-Device-Package 8-SMD
• Current-Supply 300mA
• Gain 20dB
• Amplifier-Type Power
• Test-Frequency -
• P1dB 27dBm
• Noise-Figure 7dB
• RF-Type Bluetooth
• Pd-Power-Dissipation 1.755 W
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 5 V
• Operating-Supply-Current 300 mA
• Operating-Frequency 2.8 GHz
• NF-Noise-Figure 7 dB
• P1dB-Compression-Point 27 dBm
• OIP3-Third-Order-Intercept 39 dBm
• Input-Return-Loss 8 dB
