DCR010505U Overview

Product belongs to the DCR01 series. This product is categorized as Isolated Type: Isolated Module Tube Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style Wide - 40 C to + 85 C operating temperature range for diverse applications 28-SOIC (0.295", 7.50mm Width) (12 Leads) Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Versatile ITE (Commercial) applications for maximum usability Number-of-Outputs: 1 Our product delivers a 200mA of 50mA for efficient power management. The minimum input voltage is 4.5V. The 5.5V. This product is designed with 1kV (1000V) voltage isolation for maximum safety and reliability. 5V output voltage Input Voltage Range: 4.5 V to 5.5 V 5.1 V output voltage for channel 1 Current output of channel 1 is 200 mA . Isolation voltage of 1 kV SO-28 package-case-size

DCR010505U Image

DCR010505U Specifications

• Manufacturer Texas Instruments
• Product Category DC DC Converters
• Series DCR01
• Product Isolated
• Type Isolated Module
• Packaging Tube Alternate Packaging
• Mounting-Style SMD/SMT
• Operating-Temperature-Range - 40 C to + 85 C
• Package-Case 28-SOIC (0.295", 7.50mm Width) (12 Leads)
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Surface Mount
• Features Remote On/Off, OTP, SCP
• Size-Dimension 0.70" L x 0.41" W x 0.10" H (17.9mm x 10.3mm x 2.5mm)
• Applications ITE (Commercial)
• Number-of-Outputs 1
• Current-Output-Max 200mA
• Voltage-Input-Min 4.5V
• Voltage-Input-Max 5.5V
• Voltage-Isolation 1kV (1000V)
• Output-Power 1 W
• Voltage-Output-1 5V
• Voltage-Output-2 -
• Voltage-Output-3 -
• Efficiency
• Power-Watts-Manufacture-Series 1W
• Input-Voltage 4.5 V to 5.5 V
• Output-Voltage-Channel-1 5.1 V
• Output-Current-Channel-1 200 mA
• Isolation-Voltage 1 kV
• Package-Case-Size SO-28
