BUL89

BUL89 Overview

Product belongs to the 500V Transistors series. Tube is the packaging method for this product Weight of 0.211644 oz Through Hole Mounting-Style TO-220-3 Through Hole mounting type Supplier device package: TO-220AB Configuration Single Transistor type: NPN Maximum current collector Ic is 12A . Maximum collector-emitter breakdown voltage of 400V DC current gain minimum (hFE) of Ic/Vce at 10 @ 5A, 5V. Product Attribute: Vce-Saturation-Max-Ib-Ic: 5V @ 2.4A, 12A Power-off control: 110 W Maximum operating temperature of + 150 C Minimum operating temperature: - 65 C Rated VCEO up to 400 V The transistor polarity is NPN. Saturation voltage between collector and emitter is 1 V The 850 V voltage rating is 40 V. 9 V rating of 5 V Max DC collector current: 12 A This product is capable of handling a 12 A continuous collector current. Minimum hfe for DC collector-base gain is 10. 40 of 605.

BUL89 Image

BUL89 Specifications

• Manufacturer STMicroelectronics
• Product Category Transistors (BJT) - Single
• Series 500V Transistors
• Packaging Tube
• Unit-Weight 0.211644 oz
• Mounting-Style Through Hole
• Package-Case TO-220-3
• Mounting-Type Through Hole
• Supplier-Device-Package TO-220AB
• Configuration Single
• Power-Max 110W
• Transistor-Type NPN
• Current-Collector-Ic-Max 12A
• Voltage-Collector-Emitter-Breakdown-Max 400V
• DC-Current-Gain-hFE-Min-Ic-Vce 10 @ 5A, 5V
• Vce-Saturation-Max-Ib-Ic 5V @ 2.4A, 12A
• Current-Collector-Cutoff-Max 100μA
• Frequency-Transition -
• Pd-Power-Dissipation 110 W
• Maximum-Operating-Temperature + 150 C
• Minimum-Operating-Temperature - 65 C
• Collector-Emitter-Voltage-VCEO-Max 400 V
• Transistor-Polarity NPN
• Collector-Emitter-Saturation-Voltage 1 V
• Collector-Base-Voltage-VCBO 850 V
• Emitter-Base-Voltage-VEBO 9 V
• Maximum-DC-Collector-Current 12 A
• Continuous-Collector-Current 12 A
• DC-Collector-Base-Gain-hfe-Min 10
• DC-Current-Gain-hFE-Max 40
