ADUM4152BRIZ

ADUM4152BRIZ Overview

Product belongs to the iCouplerR, SPIsolator series. This product is categorized as Digital Isolators Type: SPI Tube Alternate Packaging is the packaging method for this product Weight of 0.028254 oz SMD/SMT Mounting-Style SOIC-20 Magnetic Coupling is the technology used. Operational temperature range: -40°C ~ 125°C Number of channels: 7 Voltage Supply Range: 3 V ~ 5.5 V Supplier device package: 20-SOIC-IC This product's Unidirectional This product is designed with 5000Vrms voltage isolation for maximum safety and reliability. Power-off control: No Shutdown This product is designed with No isolated power for maximum safety and reliability. The product has 2016/4/3 0:00:00 inputs from Side 1 to Side 2. Minimum 25kV/μs of 10kV/μs Maximum Propagation Delay tpLH/tpHL: 14ns, 14ns The minimum pulse width distortion is 2ns. Power-off control: 2.4 W Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Polarity: Bidirectional Magnetic Coupling is the isolation type specified for this product. Isolation voltage of 5 kV SPI protocol is supported. The EVAL-ADuM3151Z. Maximum supply voltage of 5.5 V Minimum supply voltage is 3 V 14 ns is 23 microseconds.

ADUM4152BRIZ Image

ADUM4152BRIZ Specifications

• Manufacturer Analog Devices Inc.
• Product Category Digital Isolators
• Series iCouplerR, SPIsolator
• Product Digital Isolators
• Type SPI
• Packaging Tube Alternate Packaging
• Unit-Weight 0.028254 oz
• Mounting-Style SMD/SMT
• Package-Case SOIC-20
• Technology Magnetic Coupling
• Operating-Temperature -40°C ~ 125°C
• Number-of-Channels 7
• Voltage-Supply 3 V ~ 5.5 V
• Supplier-Device-Package 20-SOIC-IC
• Data-Rate 34Mbps
• Channel-Type Unidirectional
• Voltage-Isolation 5000Vrms
• Shutdown No Shutdown
• Rise-Fall-Time-Typ 2.5ns, 2.5ns
• Isolated-Power No
• Inputs-Side-1-Side-2 2016/4/3 0:00:00
• Common-Mode-Transient-Immunity-Min 25kV/μs
• Propagation-Delay-tpLH-tpHL-Max 14ns, 14ns
• Pulse-Width-Distortion-Max 2ns
• Pd-Power-Dissipation 2.4 W
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Polarity Bidirectional
• Isolation-Type Magnetic Coupling
• Isolation-Voltage 5 kV
• Protocol-Supported SPI
• Development-Kit EVAL-ADuM3151Z
• Supply-Voltage-Max 5.5 V
• Supply-Voltage-Min 3 V
• Propagation-Delay-Time 14 ns
