ADUM2402CRIZ

ADUM2402CRIZ Overview

Product belongs to the iCouplerR series. This product is categorized as Digital Isolators Type: General Purpose Tube Alternate Packaging is the packaging method for this product Weight of 0.023492 oz SMD/SMT Mounting-Style SOIC-16 Magnetic Coupling is the technology used. Operational temperature range: -40°C ~ 105°C Number of channels: 4 Voltage Supply Range: 2.7 V ~ 5.5 V Supplier device package: 16-SOIC-IC This product's Unidirectional This product is designed with 5000Vrms voltage isolation for maximum safety and reliability. This product is designed with No isolated power for maximum safety and reliability. The product has 2016/2/2 0:00:00 inputs from Side 1 to Side 2. Minimum 25kV/μs of 10kV/μs Maximum Propagation Delay tpLH/tpHL: 32ns, 32ns The minimum pulse width distortion is 2ns. Maximum operating temperature of + 105 C Minimum operating temperature: - 40 C Polarity: Bidirectional Magnetic Coupling is the isolation type specified for this product. 530 uA is 92 nA. Isolation voltage of 5 kVrms Maximum supply voltage of 5.5 V Minimum supply voltage is 2.7 V 32 ns is 23 microseconds. Maximum fall time of 3 ns Rise time max: 3 ns Pulse-Width: 11.1 ns

ADUM2402CRIZ Image

ADUM2402CRIZ Specifications

• Manufacturer Analog Devices Inc.
• Product Category Digital Isolators
• Series iCouplerR
• Product Digital Isolators
• Type General Purpose
• Packaging Tube Alternate Packaging
• Unit-Weight 0.023492 oz
• Mounting-Style SMD/SMT
• Package-Case SOIC-16
• Technology Magnetic Coupling
• Operating-Temperature -40°C ~ 105°C
• Number-of-Channels 4
• Voltage-Supply 2.7 V ~ 5.5 V
• Supplier-Device-Package 16-SOIC-IC
• Data-Rate 90Mbps
• Channel-Type Unidirectional
• Voltage-Isolation 5000Vrms
• Rise-Fall-Time-Typ 2.5ns, 2.5ns
• Isolated-Power No
• Inputs-Side-1-Side-2 2016/2/2 0:00:00
• Common-Mode-Transient-Immunity-Min 25kV/μs
• Propagation-Delay-tpLH-tpHL-Max 32ns, 32ns
• Pulse-Width-Distortion-Max 2ns
• Maximum-Operating-Temperature + 105 C
• Minimum-Operating-Temperature - 40 C
• Polarity Bidirectional
• Isolation-Type Magnetic Coupling
• Operating-Supply-Current 530 uA
• Isolation-Voltage 5 kVrms
• Supply-Voltage-Max 5.5 V
• Supply-Voltage-Min 2.7 V
• Propagation-Delay-Time 32 ns
• Maximum-Fall-Time 3 ns
• Maximum-Rise-Time 3 ns
• Pulse-Width 11.1 ns
