ADCMP607BCPZ-WP

ADCMP607BCPZ-WP Overview

Product belongs to the ADCMP607 series. This product is categorized as Analog Comparators Type: with Latch Tray - Waffle Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style LFCSP-12 Operational temperature range: -40°C ~ 125°C Surface Mount mounting type Output-Type: CML, Complementary, Rail-to-Rail Number of channels: 1 Channel Supplier device package: 12-LFCSP-VQ (3x3) Voltage supply range: 2.5 V ~ 5.5 V 1 element 1.5mA maximum quiescent current. Maximum propagation delay: 2.1ns Hysteresis value of 100μV Power-off control: No Shutdown Power-off control: 150 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C 1.5 mA is 92 nA. The EVAL-ADCMP607BCPZ. Maximum supply voltage of 5.5 V Minimum supply voltage is 2.5 V General Purpose comparator type Input bias current of 5 uA The 5 mV. 2.1 ns is 23 microseconds. The 50 dB. 15.8 mA The CMRR-Common-Mode-Rejection-Ratio is 50 dB.

ADCMP607BCPZ-WP Image

ADCMP607BCPZ-WP Specifications

• Manufacturer Analog Devices Inc.
• Product Category Linear - Comparators
• Series ADCMP607
• Product Analog Comparators
• Type with Latch
• Packaging Tray - Waffle Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case LFCSP-12
• Operating-Temperature -40°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type CML, Complementary, Rail-to-Rail
• Number-of-Channels 1 Channel
• Supplier-Device-Package 12-LFCSP-VQ (3x3)
• Voltage-Supply-Single-Dual 2.5 V ~ 5.5 V
• Number-of-Elements 1
• Voltage-Input-Offset-Max 5mV @ 2.5V
• Current-Input-Bias-Max 5μA @ 2.5V
• Current-Output-Typ 50mA
• Current-Quiescent-Max 1.5mA
• CMRR-PSRR-Typ 50dB CMRR, 50dB PSRR
• Propagation-Delay-Max 2.1ns
• Hysteresis 100μV
• Shutdown No Shutdown
• Pd-Power-Dissipation 150 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Current 1.5 mA
• Development-Kit EVAL-ADCMP607BCPZ
• Supply-Voltage-Max 5.5 V
• Supply-Voltage-Min 2.5 V
• Comparator-Type General Purpose
• Ib-Input-Bias-Current 5 uA
• Vos-Input-Offset-Voltage 5 mV
• Propagation-Delay-Time 2.1 ns
• PSRR-Power-Supply-Rejection-Ratio 50 dB
• Output-Current-per-Channel 15.8 mA
• CMRR-Common-Mode-Rejection-Ratio 50 dB
• GBP-Gain-Bandwidth-Product -
