ADCMP394ARZ

ADCMP394ARZ Overview

Product belongs to the ADCMP394 series. This product is categorized as Analog Comparators Type: General Purpose Tube Alternate Packaging is the packaging method for this product Weight of 0.019048 oz SMD/SMT Mounting-Style SOIC-8 The Rail to Rail for this product is CMOS/TTL. Operational temperature range: -40°C ~ 125°C Surface Mount mounting type Output-Type: Open Drain Number of channels: 1 Channel Supplier device package: 8-SOIC Voltage supply range: 2.3 V ~ 5.5 V 1 element 47.9μA maximum quiescent current. Maximum propagation delay: 4.2μs Hysteresis value of 50mV Power-off control: No Shutdown Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C 33.9 uA is 92 nA. Maximum supply voltage of 5.5 V Minimum supply voltage is 2.3 V General Purpose comparator type Input bias current of 30 nA The 5 mV. The 10 nA. 4.9 us 9.5 us is 23 microseconds. The 80 dB. The CMRR-Common-Mode-Rejection-Ratio is 74 dB.

ADCMP394ARZ Image

ADCMP394ARZ Specifications

• Manufacturer Analog Devices Inc.
• Product Category Linear - Comparators
• Series ADCMP394
• Product Analog Comparators
• Type General Purpose
• Packaging Tube Alternate Packaging
• Unit-Weight 0.019048 oz
• Mounting-Style SMD/SMT
• Package-Case SOIC-8
• Input-Type Rail to Rail
• Operating-Temperature -40°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type Open Drain
• Number-of-Channels 1 Channel
• Supplier-Device-Package 8-SOIC
• Voltage-Supply-Single-Dual 2.3 V ~ 5.5 V
• Number-of-Elements 1
• Voltage-Input-Offset-Max 5mV
• Current-Input-Bias-Max 30nA
• Current-Output-Typ -
• Current-Quiescent-Max 47.9μA
• CMRR-PSRR-Typ 74dB CMRR, 80dB PSRR
• Propagation-Delay-Max 4.2μs
• Hysteresis 50mV
• Shutdown No Shutdown
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Current 33.9 uA
• Supply-Voltage-Max 5.5 V
• Supply-Voltage-Min 2.3 V
• Comparator-Type General Purpose
• Ib-Input-Bias-Current 30 nA
• Vos-Input-Offset-Voltage 5 mV
• Ios-Input-Offset-Current 10 nA
• Propagation-Delay-Time 4.9 us 9.5 us
• PSRR-Power-Supply-Rejection-Ratio 80 dB
• CMRR-Common-Mode-Rejection-Ratio 74 dB
• GBP-Gain-Bandwidth-Product -
