AD9058AJD

AD9058AJD Overview

Product belongs to the AD9058 series. This product is categorized as Analog to Digital Converters Tube is the packaging method for this product Through Hole Mounting-Style CDIP-SB-48 The Single Ended for this product is CMOS/TTL. Operational temperature range: 0°C ~ 70°C Number of channels: 2 Channel Supplier device package: 48-CDIP Side Brazed Solder Lid This product's 50M. Data-Interface: Parallel 8 bits The Voltage-Supply-Analog is ±5V. The Voltage Supply Digital for this product is ±5V. Configuration ADC The architecture of this product is Flash . Internal is the reference type. 2 units Power-off control: 770 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 55 C This product has a Power Consumption of 770 mW. Parallel interface type Signal-to-Noise Ratio of 48 dB Number-of-Converters: 2 Converter 50 MS/s Sampling Rate Integral Nonlinearity: 1.4 LSB Differential nonlinearity: 0.8 LSB

AD9058AJD Image

AD9058AJD Specifications

• Manufacturer AD
• Product Category Data Acquisition - Analog to Digital Converters (ADC)
• Series AD9058
• Product Analog to Digital Converters
• Packaging Tube
• Mounting-Style Through Hole
• Package-Case CDIP-SB-48
• Input-Type Single Ended
• Operating-Temperature 0°C ~ 70°C
• Features Simultaneous Sampling
• Number-of-Channels 2 Channel
• Supplier-Device-Package 48-CDIP Side Brazed Solder Lid
• Sampling-Rate-Per-Second 50M
• Data-Interface Parallel
• Number-of-Bits 8
• Voltage-Supply-Analog ±5V
• Voltage-Supply-Digital ±5V
• Configuration ADC
• Architecture Flash
• Number-of-Inputs 2
• Resolution 8 bit
• Reference-Type Internal
• Ratio-S-H:ADC -
• Number-of-A-D-Converters 2
• Pd-Power-Dissipation 770 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 55 C
• Power-Consumption 770 mW
• Interface-Type Parallel
• SNR-Signal-to-Noise-Ratio 48 dB
• Number-of-Converters 2 Converter
• Sampling-Rate 50 MS/s
• INL-Integral-Nonlinearity 1.4 LSB
• DNL-Differential-Nonlinearity 0.8 LSB
