AD8178ABPZ Overview

Product belongs to the AD8178 series. This product is categorized as Video Crosspoint Switches Tube is the packaging method for this product SMD/SMT Mounting-Style BGA Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Product function is Video Crosspoint Switch. Supplier device package: 676-BGA (27x27) - is 8. Voltage supply source: Analog and digital Single, Dual Supply Configuration Triple 16 x 5 Circuit type: 3 x 16:5 - maximum on-state resistance Voltage supply range: 4.5 V ~ 5.5 V, ±2.5V This product has a 460mA of 200μA. The - 450 MHz bandwidth Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 2.5 V supply voltage for reliable performance. The AD8178-EVALZ. Maximum supply voltage of 2.5 V Minimum supply voltage is 2.5 V Maximum dual supply voltage: +/- 2.75 V 5.5 V 6 V Minimum dual supply voltage of +/- 2.25 V 4.5 V Dual Triple supply type

AD8178ABPZ Image

AD8178ABPZ Specifications

• Manufacturer Analog Devices Inc.
• Product Category Interface - Analog Switches, Multiplexers, Demultiplexers
• Series AD8178
• Product Video Crosspoint Switches
• Packaging Tube
• Mounting-Style SMD/SMT
• Package-Case BGA
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Surface Mount
• Function Video Crosspoint Switch
• Supplier-Device-Package 676-BGA (27x27)
• Number-of-Circuits -
• Voltage-Supply-Source Single, Dual Supply
• Configuration Triple 16 x 5
• Switch-Circuit -
• Circuit 3 x 16:5
• Multiplexer-Demultiplexer-Circuit -
• On-State-Resistance-Max -
• Channel-to-Channel-Matching-ΔRon -
• Voltage-Supply-Single-Dual 4.5 V ~ 5.5 V, ±2.5V
• Current-Supply 460mA
• Voltage-Supply-Single-V+ -
• Voltage-Supply-Dual-V -
• Switch-Time-Ton-Toff-Max -
• -3db-Bandwidth -
• Charge-Injection -
• Channel-Capacitance-CS-off-CD-off -
• Current-Leakage-IS-off-Max -
• Crosstalk -
• Bandwidth 450 MHz
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 2.5 V
• Development-Kit AD8178-EVALZ
• Supply-Voltage-Max 2.5 V
• Supply-Voltage-Min 2.5 V
• Maximum-Dual-Supply-Voltage +/- 2.75 V 5.5 V 6 V
• Minimum-Dual-Supply-Voltage +/- 2.25 V 4.5 V
• Supply-Type Dual Triple
