AD7788ARM Overview

Product belongs to the AD7788 series. This product is categorized as Analog to Digital Converters Tube is the packaging method for this product Weight of 0.005051 oz SMD/SMT Mounting-Style MSOP-10 The Differential for this product is CMOS/TTL. Operational temperature range: -40°C ~ 85°C Number of channels: 1 Channel Supplier device package: 10-MSOP This product's 16.6. Data-Interface: SPI, DSP 16 bits The Voltage-Supply-Analog is 2.5 V ~ 5.25 V. The Voltage Supply Digital for this product is 2.5 V ~ 5.25 V. Configuration ADC The architecture of this product is Sigma-Delta . External is the reference type. 1 units Power-off control: 400 uW Maximum operating temperature of + 105 C Minimum operating temperature: - 40 C Serial 3-Wire SPI interface type The +/- 10 uV of this product is 0.2%. Number-of-Converters: 1 Converter 16.6 S/s Sampling Rate Integral Nonlinearity: +/- 50 ppm of FSR

AD7788ARM Image

AD7788ARM Specifications

• Manufacturer Analog Devices Inc.
• Product Category Data Acquisition - Analog to Digital Converters (ADC)
• Series AD7788
• Product Analog to Digital Converters
• Packaging Tube
• Unit-Weight 0.005051 oz
• Mounting-Style SMD/SMT
• Package-Case MSOP-10
• Input-Type Differential
• Operating-Temperature -40°C ~ 85°C
• Features -
• Number-of-Channels 1 Channel
• Supplier-Device-Package 10-MSOP
• Sampling-Rate-Per-Second 16.6
• Data-Interface SPI, DSP
• Number-of-Bits 16
• Voltage-Supply-Analog 2.5 V ~ 5.25 V
• Voltage-Supply-Digital 2.5 V ~ 5.25 V
• Configuration ADC
• Architecture Sigma-Delta
• Number-of-Inputs 1
• Resolution 16 bit
• Reference-Type External
• Ratio-S-H:ADC -
• Number-of-A-D-Converters 1
• Pd-Power-Dissipation 400 uW
• Maximum-Operating-Temperature + 105 C
• Minimum-Operating-Temperature - 40 C
• Interface-Type Serial 3-Wire SPI
• Gain-Error +/- 10 uV
• Number-of-Converters 1 Converter
• Sampling-Rate 16.6 S/s
• INL-Integral-Nonlinearity +/- 50 ppm of FSR
