AD7714AR-3

AD7714AR-3 Overview

Product belongs to the AD7714 series. This product is categorized as Analog to Digital Converters Tube is the packaging method for this product Weight of 0.038731 oz SMD/SMT Mounting-Style SOIC-24 The Differential, Pseudo-Differential for this product is CMOS/TTL. Operational temperature range: -40°C ~ 85°C Number of channels: 5 Channel Supplier device package: 24-SOIC This product's 1k. Data-Interface: SPI, DSP 24 bits The Voltage-Supply-Analog is 3 V ~ 3.6 V. The Voltage Supply Digital for this product is 3 V ~ 5.25 V. Configuration MUX-PGA-ADC The architecture of this product is Sigma-Delta . External is the reference type. 1 units Power-off control: 7 mW Maximum operating temperature of + 105 C Minimum operating temperature: - 40 C This product has a Power Consumption of 5 mW. Serial 3-Wire SPI interface type Signal-to-Noise Ratio of 137 dB The EVAL-AD7714-3EBZ. The +/- 0.003 %FSR of this product is 0.2%. Number-of-Converters: 1 Converter 1 kS/s Sampling Rate Integral Nonlinearity: +/- 0.0015 %FSR

AD7714AR-3 Image

AD7714AR-3 Specifications

• Manufacturer AD
• Product Category Data Acquisition - Analog to Digital Converters (ADC)
• Series AD7714
• Product Analog to Digital Converters
• Packaging Tube
• Unit-Weight 0.038731 oz
• Mounting-Style SMD/SMT
• Package-Case SOIC-24
• Input-Type Differential, Pseudo-Differential
• Operating-Temperature -40°C ~ 85°C
• Features PGA
• Number-of-Channels 5 Channel
• Supplier-Device-Package 24-SOIC
• Sampling-Rate-Per-Second 1k
• Data-Interface SPI, DSP
• Number-of-Bits 24
• Voltage-Supply-Analog 3 V ~ 3.6 V
• Voltage-Supply-Digital 3 V ~ 5.25 V
• Configuration MUX-PGA-ADC
• Architecture Sigma-Delta
• Number-of-Inputs
• Resolution 24 bit
• Reference-Type External
• Ratio-S-H:ADC -
• Number-of-A-D-Converters 1
• Pd-Power-Dissipation 7 mW
• Maximum-Operating-Temperature + 105 C
• Minimum-Operating-Temperature - 40 C
• Power-Consumption 5 mW
• Interface-Type Serial 3-Wire SPI
• SNR-Signal-to-Noise-Ratio 137 dB
• Development-Kit EVAL-AD7714-3EBZ
• Gain-Error +/- 0.003 %FSR
• Number-of-Converters 1 Converter
• Sampling-Rate 1 kS/s
• INL-Integral-Nonlinearity +/- 0.0015 %FSR
