AD7524JP Overview

Product belongs to the AD7524 series. This product is categorized as Digital to Analog Converters Tube is the packaging method for this product Weight of 0.025468 oz SMD/SMT Mounting-Style PLCC-20 Operational temperature range: -40°C ~ 85°C Output-Type: Current - Unbuffered Number of channels: 1 Channel Supplier device package: 20-PLCC (9x9) Data-Interface: Parallel 8 bits The Voltage-Supply-Analog is 5 V ~ 15 V. The Voltage Supply Digital for this product is 5 V ~ 15 V. The architecture of this product is R-2R . External is the reference type. Number of D-A converters: 1 The 500μs is an impressive 15 us. Yes Differential-Output Power-off control: 450 mW Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C 2 mA is 92 nA. Parallel interface type Maximum supply voltage of 15 V Minimum supply voltage is 5 V Number-of-Converters: 1 Converter 4 MS/s Sampling Rate

AD7524JP Image

AD7524JP Specifications

• Manufacturer Analog Devices Inc.
• Product Category Data Acquisition - Digital to Analog Converters (DAC)
• Series AD7524
• Product Digital to Analog Converters
• Packaging Tube
• Unit-Weight 0.025468 oz
• Mounting-Style SMD/SMT
• Package-Case PLCC-20
• Operating-Temperature -40°C ~ 85°C
• Output-Type Current - Unbuffered
• Number-of-Channels 1 Channel
• Supplier-Device-Package 20-PLCC (9x9)
• Data-Interface Parallel
• Number-of-Bits 8
• Voltage-Supply-Analog 5 V ~ 15 V
• Voltage-Supply-Digital 5 V ~ 15 V
• Architecture R-2R
• Resolution 8 bit
• Reference-Type External
• Number-of-D-A-Converters 1
• Settling-Time 500μs
• Differential-Output Yes
• INL-DNL-LSB ±0.5 (Max), -
• Pd-Power-Dissipation 450 mW
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Current 2 mA
• Interface-Type Parallel
• Supply-Voltage-Max 15 V
• Supply-Voltage-Min 5 V
• Number-of-Converters 1 Converter
• Sampling-Rate 4 MS/s
