AD558KP

AD558KP Overview

Product belongs to the DACPORTR series. This product is categorized as Digital to Analog Converters Type: Precision DAC Tube is the packaging method for this product Weight of 0.025468 oz SMD/SMT Mounting-Style PLCC-20 Operational temperature range: 0°C ~ 70°C Output-Type: Voltage - Buffered Number of channels: 1 Channel Supplier device package: 20-PLCC (9x9) Data-Interface: Parallel 8 bits The Voltage-Supply-Analog is 4.5 V ~ 16.5 V. The Voltage Supply Digital for this product is 4.5 V ~ 16.5 V. The architecture of this product is R-2R . Internal is the reference type. Number of D-A converters: 1 The 3μs is an impressive 15 us. No Differential-Output Power-off control: 375 mW Maximum operating temperature of + 70 C Minimum operating temperature: 0 C 15 mA is 92 nA. Parallel interface type Maximum supply voltage of 16.5 V Minimum supply voltage is 4.5 V Number-of-Converters: 1 Converter Integral Nonlinearity: +/- 0.25 LSB

AD558KP Image

AD558KP Specifications

• Manufacturer Analog Devices Inc.
• Product Category Data Acquisition - Digital to Analog Converters (DAC)
• Series DACPORTR
• Product Digital to Analog Converters
• Type Precision DAC
• Packaging Tube
• Unit-Weight 0.025468 oz
• Mounting-Style SMD/SMT
• Package-Case PLCC-20
• Operating-Temperature 0°C ~ 70°C
• Output-Type Voltage - Buffered
• Number-of-Channels 1 Channel
• Supplier-Device-Package 20-PLCC (9x9)
• Data-Interface Parallel
• Number-of-Bits 8
• Voltage-Supply-Analog 4.5 V ~ 16.5 V
• Voltage-Supply-Digital 4.5 V ~ 16.5 V
• Architecture R-2R
• Resolution 8 bit
• Reference-Type Internal
• Number-of-D-A-Converters 1
• Settling-Time 3μs
• Differential-Output No
• INL-DNL-LSB ±0.25 (Max), -
• Pd-Power-Dissipation 375 mW
• Maximum-Operating-Temperature + 70 C
• Minimum-Operating-Temperature 0 C
• Operating-Supply-Current 15 mA
• Interface-Type Parallel
• Supply-Voltage-Max 16.5 V
• Supply-Voltage-Min 4.5 V
• Number-of-Converters 1 Converter
• INL-Integral-Nonlinearity +/- 0.25 LSB
